Features:

1.Compliant with DP1.4

2.Support video format up to 8K@60Hz with 24bit RGB/YcbCR 4:4:4/YCBCR4:4:4, and up to 8K@60Hz with 12bit YCBCR 4:4:4.

3.Support 3D frame sequential video format up to 1080p@60.

4.Support high resolution VESA mode video format up to QSXGA@60Hz. 5.Support HDR and 18Gbps Signal Speed.

5.Supports LPCM 7.1CH, Dolby True HD, and DTS-HD Master Audio. 7.Extend the transmission distance and improve transmission signal. 8.Metal casing design and overall shielding without signal interference.

Packaging accessories:

1. DP Switch----------------------------------------------------------1 Pcs

2. USB Power Cable------------------------------------------------1 Pcs

Technical parameters

Single Link Range--------------------------------------------------------------7680x4320

Input Video Signal------------------------------------------------------0.5-1.0 Volts P-P

Input DDC Signal--------------------------------------------------------5 Volts P-P(TTL)

Deep Color------------------------------------------------------------------------------48 bit

DP Version------------------------------------------------------------------------------DP1.4

Bandwidth--------------------------------------------------------------------Up to 600MHz

Signal Speed-----------------------------------------------------------------Up to 18Gbps

The length of input cable-------------------------------------------------------------≤10M

The length of output cable-----------------------------------------------------------≤10M

The cable standard------------------------------------------------------------------28AWG

Vertical Frequency Range------------------------------------------------------------60Hz

Power Consumption(max.)-------------------------------------------------------0.5Watts

Operation Temperature-----------------------------------------------------------0℃-70℃

Net Weight------------------------------------------------------------------------------0.03Kg

Dimension: L*W*H(mm)-----------------------------------------------------53.9x52x15.4

Packaging accessories:

1. DP Switch----------------------------------------------------------1 Pcs

2. USB Power Cable------------------------------------------------1 Pcs
