4K@30Hz 1x2 HDMI Splitter Extender via Cat5e/6 100m MZ102EX100A
1.0 Introduction:
The HDMI splitter extender is a product designed for splitting and extending your HDMI signal over long distances to a compatible display. It uses a single CAT5e/6 or higher-level cable up to 100 meters instead of an HDMI cable to transmit high-definition signals. The HDMI signal is distributed from source devices such as DVD players, Satellite Receivers, Set-Top Boxes, DV Cameras, AV Receivers, and other HDMI-enabled devices to one or more high-definition display devices like HDTVs and HDMI Flat Panel Displays.
2.0 Features:
One HDMI input signal split into multiple HDMI outputs over CAT5e/6 RJ45 cable.
Transmission distance: CAT5e/6 or higher-level RJ45 cable up to 100 meters.
Supports HDMI 1.4 and HDCP 1.4 protocol.
Video format support: 4K@30Hz, 1080p, 720p, 576p, 480p.
Audio format support: DTS-HD/Dolby-TrueHD/LPCM 7.1/DTS/Dolby-AC3/DSD.
Transmitter supports HDMI loopout.
Support EDID select.
Support POC (Power Over Cable) and 20-60KHz IR passthrough.
Easy to install, plug and play, no drivers needed.
DC/12V power supply.
3.0 Packaging Accessories:
When first unpacking your extender, please check to see if the following items are included:
HDMI Splitter/Extender Transmitter ---------------------- 1 PC
HDMI Receiver ---------------------------------------------- 2/4/8 PCs (Please choose the correct quantity)
IR-TX Cable ----------------------------------------------- 1 PC
IR-RX Cable ----------------------------------------------- 2/4/8 PCs (Matches receiver quantity)
Power Supply ----------------------------------------------- 1 PC
User Manual ------------------------------------------------ 1 PC
3.0 Packaging Accessories:
When first unpacking your extender, please check to see if the following items are included:
HDMI Splitter/Extender Transmitter ---------------------- 1 PC
HDMI Receiver ---------------------------------------------- 2/4/8 PCs (Please choose the correct quantity)
IR-TX Cable ----------------------------------------------- 1 PC
IR-RX Cable ----------------------------------------------- 2/4/8 PCs (Matches receiver quantity)
Power Supply ----------------------------------------------- 1 PC
User Manual ------------------------------------------------ 1 PC
