MZ2042E 4K@60Hz 4x2 HDMI Matrix with EDID HDMI2.0
FEATURES
1.When its 4 input ports are separately connected to 4 signal sources
with HDMI cables, the HDMI Matrix automatically recognizes the last
connected port and switches its input signal to 2 displays;
2.The needed input signal sources must be selected by using remote
control or pushing button in order to make 2 displays showing 2 different
Signals;
3.Support HDMI2.0,HDCP2.2,HDR;
4. Support video format up to 4k2k@60Hz with 24bit RGB/YcbCR
4:4:4/YCBCR4:4:4,and up to 4k2k@60Hz with 12bit YCBCR 4:4:4;
5. Switch easily between any 4 HDMI sources.
6. Support ARC and Audio Extractor(Output A);
7. The 2 displays can get the same or different signals without mutual
interaction.
8. Connected easily to dual-channel audio receiver device.
9. Support DVI device with DVI to HDMI adapter.
10. Plug-and-play and no need of setting.
11. Metal casing design and overall shielding without signal interference.
12. Use remote control or push button to freely select input source.
13. LED indicates signal /power mode.
PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following items are contained in the shipping carton:
1.HDMI 4X2 Matrix ---------------------1PCS
2.DC 5V Power adapter----------------1PCS
3.Remote control-------------------------1PCS
4.User Manual----------------------------1PCS
TECHNICAL PARAMETERS
HDMI Source Input Port | 4 |
Display Device Output Port | 2 |
Audio Output port | SPDIFx1,Stereox1 |
Source Port Connector | HDMI 19PIN |
Display Device Port Connector | HDMI 19PIN |
HDCP Compliant | YES |
Single Link Range | 3840x2160 |
Input Video Signal | 0.5-1.0 Volts P-P |
Input DDC Signal | 5 Volts P-P(TTL) |
Deep Color | 36bit |
HDMI Version | HDMI2.0 |
Bandwidth | Up to 600Mhz |
Signal Speed | Up to 18Gbps |
The length of input cable | PS3≤10M；BLUE DVD≤10M |
The length of output cable | ≤10M |
The cable standard | 26AWG HDMI2.0 |
Vertical Frequency Range | 60Hz |
Power Consumption(max.) | 6.5Watts |
Operation Temperature | 0℃-70℃ |
Working Voltage | DC 5V |
Power Adaptor | 5V 2A |
Net Weight | 0.6kg |
Dimension: L*W*H(mm) | 200x94x21.5 |
Explanation: With different brands of the input or output device, the length of the connecting cables will differ too.
