Features

• Transmission Distance: CAT5e/6 or higher level cable up to 100M.

• HDMI & HDCP Support: Supports HDMI 1.4 and HDCP 1.4 protocol.

• Video Resolutions: Supports 4Kx2K@30Hz / 1080p / 720p / 576p / 480p.

• 3D Support: Supports 3D frame sequential video format up to 1080P@60Hz.

• Audio Formats: Supports DTS-HD / Dolby-trueHD / LPCM7.1 / DTS / Dolby-AC3 / DSD.

• Transmitter Loopout: Transmitter supports HDMI loopout.

• EDID Select: Supports EDID select function.

• IR Pass-through: Supports 20-60KHz IR pass-through.

• PoC (Power over Cable): Supports PoC for simplified power.

• Power Supply: DC 5V/12V power supply.

• Plug & Play: Easy to install, plug and play, no drivers needed.

Packaging Contents

When first unpacking your extender, please check to see if the following items are included:

1. HDMI Transmitter – 1 PCS

2. HDMI Receiver – 1 PCS

3. IR-TX Cable – 1 PCS

4. IR-RX Cable – 1 PCS

5. Power Supply – 1 PCS

6. User Manual – 1 PCS

Technical Parameters

• Length of CAT5e/6 cable between Transmitter and Receiver: Up to 100 meters

• Supported Video Resolution: 4Kx2K@30Hz / 1080p / 720p / 576p / 480p

• Supported Audio Formats: DTS-HD / Dolby-trueHD / LPCM7.1 / DTS / Dolby-AC3 / DSD

• Max Bandwidth: 340MHz

• Max Baud Rate: 10.2Gbps

• Video Input Signal: 0.5~1.5Volts p-p

• DDC Output Signal: 5Volts p-p (TTL)

• Input/Output HDMI Cable Length: ≤20m 26AWG HDMI standard cable

• Max Working Current: 800mA

• Power Adaptor Format: Input: AC 100V-240V (50Hz/60Hz); Output: DC12V/1A

• Operating Temperature Range: -10 to +45°C

• Operating Humidity Range: 5 to 90% RH (No condensation)

• Dimension (L x W x H): 78.5 x 88 x 17 mm

Packaging Contents

When first unpacking your extender, please check to see if the following items are included:

1. HDMI Transmitter – 1 PCS

2. HDMI Receiver – 1 PCS

3. IR-TX Cable – 1 PCS

4. IR-RX Cable – 1 PCS

5. Power Supply – 1 PCS

6. User Manual – 1 PCS
