FEATURES

1. Transmission Distance: CAT5e or higher-level cable supports transmission up to 120 meters.

2. HDMI Compatibility: Supports HDMI 1.3 and HDCP 1.2 protocols.

3. Video Resolutions Supported: 1080p, 720p, 576p, 480p.

4. Video Format Support: Supports frame sequential video formats up to 1080p@60Hz.

5. Audio Format Support:
     - DTS-HD
     - Dolby TrueHD
     - LPCM 7.1
     - DTS
     - Dolby AC3
     - DSD

6. HDMI Loopout: Transmitter supports HDMI loop output.

7. IR Control: Supports 18–50KHz IR pass-through.

8. Power over Cable (PoC): Supports PoC function.

9. Power Supply: DC 12V required.

10. Installation: Easy setup, plug and play. No drivers needed.

PACKAGING ACCESSORIES

When first unpacking your extender, please check to ensure the following items are included:

• HDMI Transmitter × 1 PCS

• HDMI Receiver × 1 PCS

• IR-TX Cable × 1 PCS

• IR-RX Cable × 1 PCS

• Power Supply × 1 PCS

• User Manual × 1 PCS

TECHNICAL PARAMETERS

• Length of CAT5e/6 Cable (TX to RX): Up to 120 meters

• Supported Video Resolutions: 1080p, 720p, 576p, 480p

• Supported Audio Formats: DTS-HD, Dolby TrueHD, LPCM 7.1, DTS, Dolby AC3, DSD

• Max Bandwidth: 165 MHz

• Max Baud Rate: 4.35 Gbps

• Video Input Signal: 0.5–1.5 Volts p-p

• DDC Output Signal: 5 Volts p-p (TTL)

• HDMI Cable Distance: ≤ 20m using 28AWG HDMI standard cable

• Max Working Current: 800 mA

• Power Adapter Format:
    Input: AC 100V–240V (50Hz/60Hz)
    Output: DC 12V / 1A

• Operating Temperature Range: -40°C to +85°C

• Operating Humidity Range: 5%–90% RH (No Condensation)

• Product Dimensions (L×W×H): 78.5 × 58 × 17 mm
