1080P 50m H.265 Wireless HDMI Extender MZWS050

MZWS050 H.265 Wireless HDMI Extender, delivering crisp 1080P video up to 50m. Perfect for seamless AV transmission in conference rooms, retail displays, or home theaters. Enjoy low-latency streaming with plug-and-play setup for professional and engineering applications.
Description Package Information Inquiry

2.0 Features:

1. HDMI video and audio transmission via wireless WIFI, up to 50-100 meters;

2. HDMI 1.3 compatible;

3. In accordance with standard HDCP1.2 ,high-bandwidth digital content

protection technology;

4. HD video signal resolution up to 1920x1080@60Hz;

5. Special format is to compress and decompress video,effectively improve

the transfer efficiency,to ensure that the playback fluency;

6. Able to automatically identify and configure a variety of display mode;

7. Built-in automatic balance system, the picture is fluent, clear and stable;

8. The built-in ESD electrostatic protection circuit, comprehensive security

protection system;

9. Simple and convenient installation, plug and play, do not need to set up.



3.0 Packaging accessories:

1. HDMI transmitter------------------------------------------------1 PCS

2. HDMI receiver ---------------------------------------------------1 PCS

3. 12V DC Power Adaptor-----------------------------------------2 PCS

4. User Manual------------------------------------------------------1 PCS



4.0 Technical parameters:

Parameter

Description

Video

Standards

HDMI 1.3; HDCP 1.2

Compressed format

H.265

Maximum pixel clock

165MHz

Maximum data rate

6.75Gbps

Resolution

Max: 1920X1080p@60Hz

Connector

HDMI-A

Impedance

100Ω

Recommend HDMI maximum input/output range

Less than 5 meters, when 1920 x1080p @ 60 Hz

WIFI

Radio Frequency power

13dbm

Wireless standards

802.11ac

signal direction

Unidirectional

Radio frequency

5.8GHz

Transmission distance

100M(Max)

Other

Power

Adapter:DC 12V

Power dissipation

MAX 5W

Temperature

Operating-5℃ ~ +70℃

Humidity

Operating5% ~ 90%

Size

120*73*22mm

Warranty

1 year free warranty


Packaging accessories:

1. HDMI transmitter------------------------------------------------1 PCS

2. HDMI receiver ---------------------------------------------------1 PCS

312V DC Power Adaptor-----------------------------------------2 PCS

4. User Manual------------------------------------------------------1 PCS
